Yamaha Genuine Regulator Rectifier Assembly 5TL-H1960-00 for Mio Sporty Mio Soul Amore

Yamaha Genuine rectifier and voltage regulator assembly for selected carbureted Yamaha Mio models using OEM part number 5TL-H1960-00. It converts the stator’s AC output to DC and regulates charging voltage for the battery and motorcycle electrical system.

Also searched as regulator, rectifier, charger, voltage regulator, kiprok, or charging-system regulator.

Product specifications

• Brand: Yamaha Genuine Parts
• Part number: 5TL-H1960-00
• Product type: Rectifier and Regulator Assembly
• Manufacturer marking: SH656A-12
• Electrical system: 12V motorcycle system
• Connector: Green 2-pin / 2-terminal plug
• Housing: Finned aluminum heat-dissipation body
• Mounting: Single mounting hole
• Installation: Plug-in, model-specific replacement
• Quantity: 1 piece
• Color: Silver with green connector

Primary applications

• Yamaha Mio Sporty
• Yamaha Mio Amore
• Yamaha Mio Soul carburetor models
• Selected early Yamaha Mio 115 carburetor variants

The same part number may also appear on selected older Yamaha Nouvo 115 and T135/Sniper 135 versions. Confirm the existing regulator code before ordering because applications vary by year, wiring harness, and market version.

Available size and connector type

• One OEM size only: 5TL-H1960-00
• 12V configuration
• 2-pin green connector
• SH656A-12-type aluminum housing

This listing is not for 4-pin, 5-pin, or fuel-injected-model regulators.

Equivalent and cross-reference

• Shindengen reference: SH656A-12
• Unit marking: 5TL-00
• Aftermarket search reference: 5TL-H1960-00 / SH656A-12 / 12V 2-pin regulator

There is no confirmed direct Honda, Suzuki, or Kawasaki OEM equivalent. A similar-looking two-pin regulator is not automatically compatible. Any aftermarket replacement must match:

• Exact two-pin connector shape
• Terminal position and polarity
• 12V charging-system design
• Regulator/rectifier circuit type
• Mounting-hole position
• Housing dimensions and heat-dissipation capacity

Package inclusion

• 1 × Yamaha Rectifier and Regulator Assembly
• Mounting bolt, wiring harness, battery, stator, and other electrical parts are not included unless specifically stated.

Important reminder

Please compare the OEM number, connector, and physical appearance with the existing part before checkout. A charging problem may also be caused by the battery, stator, ground connection, fuse, or damaged wiring. Installation and electrical testing by a qualified motorcycle technician are recommended.
